Combi Packaging System's side belt drive case erecting machines form and bottom seal cases at speeds up to 15 cases per minute. This bottom sealing machine is built with the same optimal durability, reliability and value the 2-EZ® family of case erectors has provided over the years. Our case erecting machine is engineered with the industry's strongest frame (lifetime warranty) for the most demanding 3-shift environments and can readily integrate into your existing line. Combi's EZ-load walk-in powered case magazine and 3-minute "No Tool" changeover system are standard features. The 2-EZ® side belt drive units are designed for years of dependable service and can form and seal the widest variety of cases, from single wall to triple wall corrugated.
| Model | 2-EZ SB |
|
Case Size Min |
8 x 6 x 5" (203x152x127mm) |
| Case Size Max (L x W x H) |
24" x 16" x 18" (610x406x457mm) |
| Speed: Cases per minute* | 8-20" length 15 cpm 20-24" length 12 cpm |
| Overall System Footprint | 8'4" x 8'4" (254x254cm) |
The flat case blank stands vertically in the easy to load, walk-in magazine. The case blank is extracted from the magazine with vacuum cups and formed by a retracting squaring arm. The leading minor flap is folded using a pneumatic flap folding mechanism. The major flaps are folded up using a rotary actuator powered flap folding mechanism. The case is transferred into the dual belt drives where it is transported across the tape head and is bottom sealed with a 2" wide strip of pressure-sensitive tape.
Heavy-Duty Locking Casters
Low Case Supply Alarm
Low Tape/No Tape Alarm Kit
3" and 6" Wide Tape Heads
Spare Parts Kit
Over-sized Case Modification
Stainless Steel Framework
NEMA 4 Water Wash Down
